JBL Ultimate Karaoke Package | MK10 + Crown XLi-1500 + KX180 + Pasion-12SP + U-X8 Wireless Mic

JBL MK10 – 10″ 250W Professional Karaoke Speakers (Pair)

• System Type: 10″, 2-way, bass-reflex design

• Power Handling: 250 W continuous / 500 W program / 1000 W peak

• Frequency Response (−10 dB): 45 Hz – 18 kHz

• Frequency Response (±3 dB): 65 Hz – 15 kHz

• Sensitivity: 90 dB

• Max SPL: 113 dB continuous (119 dB peak)

• Nominal Impedance: 8 Ω

• Coverage: 120° × 100°

• Drivers: 1 × 10″ woofer, 3 × 3″ tweeters

• Dimensions (H × W × D): 285 × 520 × 320 mm

• Net Weight: ~13.5 kg (each)

Crown XLi-1500 – Professional Power Amplifier

• Stereo Power Output: 2 × 330 W @ 8 Ω; 2 × 450 W @ 4 Ω

• Bridged Mono Output: 900 W @ 8 Ω

• Frequency Response: 20 Hz – 20 kHz (+0/−1 dB)

• Total Harmonic Distortion (THD): < 0.5%

• Signal-to-Noise Ratio: > 100 dB

• Damping Factor: > 200

• Input Sensitivity: 0.775 V or 1.4 V selectable

• Inputs: Balanced XLR & ¼″ TRS

• Outputs: Binding posts & Speakon connectors

• Dimensions (W × H × D): 483 × 89 × 315 mm (2U rackmount)

• Net Weight: 12.7 kg

JBL KX180 – Professional Digital Karaoke Processor

• Functions: EQ, crossover, limiter, delay, compressor, feedback suppression

• Inputs: 2 × Mic, 2 × Stereo Line, Optical, USB

• Outputs: 6 (configurable for mains, subs, monitors)

• Frequency Response: 20 Hz – 20 kHz

• S/N Ratio: > 90 dB

• THD: < 0.05%

• Control: Front panel + PC software (via USB)

• Dimensions (W × H × D): 484 × 45 × 210 mm (1U rackmount)

• Net Weight: 2.5 kg

JBL Pasion-12SP – 12” Active Subwoofer

• Power Output: 300 W RMS / 450 W dynamic

• Frequency Response: 40 Hz – 160 Hz

• Sensitivity: 95 dB

• Variable Crossover: 40 Hz – 160 Hz, 24 dB/octave

• Inputs/Outputs: RCA L+R, XLR with link outputs

• Power Supply: 100–240 V AC, 50/60 Hz

• Dimensions (H × W × D): 396 × 464 × 430 mm

• Net Weight: 22.65 kg

Master-D U-X8 Pro Vocal – UHF Wireless Microphone System

• Frequency Range: 600 – 700 MHz

• Wireless Channels: Dual-channel UHF

• Frequency Response: 50 Hz – 18 kHz

• Signal-to-Noise Ratio: > 90 dB

• Distortion: ≤ 0.5% @ 1 kHz

• Range: Up to 50 m (line-of-sight)

• Power: Rechargeable (via USB / 18650 batteries)

• Included: Receiver + 2 handheld wireless microphones
